Bridge type Machining Centre NICOLAS CORREA - EURO 2000 - CNC SELCA 4045
New in Stock
Bridge type Machining Centre NICOLAS CORREA - EURO 2000 - CNC SELCA 4045
Contact us for price
Location:Lonate Pozzolo, Italy
Description
Bridge type Machining Centre NICOLAS CORREA EURO 2000 - 18.000 rpm - capacity 2000x1250x650 mm, CNC SELCA 4045
Specifications
| Manufacturer | NICOLAS CORREA |
| Model | EURO 2000 |
| Year | 2005 |
| Condition | Used |
| Stock Number | CL086 |
| Working table size | 2300x1000 mm |
| Longitudinal travel x axis | 2000 mm |
| Cross travel y axis | 1250 mm |
| Vertical travel z axis | 650 mm |
| Measurement system | HEIDENHAIN optical scales |
| Working feed x-y-z axes | 0 - 30.000 mm/1' |
| Rapid feed x-y-z axes | 30.000 mm/1' |
| Spindle taper type | HSK 63 |
| Automatic tools change nr. | 40 |
| Spindle speed | 0- 18.000 rpm |
| Spindle motor power | 20 Kw |
| Cnc | SELCA 4045 |
| Approx net weight | 20.000 Kg |
| Accessories | through-spindle coolant, chip conveyor |
Additional Features
Information about technical data are not binding.
Machine available subject to prior sale.
